15S60A BMS for Medical equipment - AYAA TECHNOLOGY CO., LTD

Model Number PCM-L15S60-E92(A-1) Communication Interface SMBUS Charging voltage DC：58.8V CC/CV（4.2v/Cell）14s Maximal continuous charging current 30A Maximal continuous discharging current 30A Current consume in normal operation ≤600uA Balance current for single cell 42±10mA Balance voltage for single cell 4.20±0.10V Over charge detection voltage 4.25±0.05V Over discharge detection voltage 25±3A Charge Over current detection current 1 / ChargeOver current detection current 2 / Discharge Over current detection current 1 32±3A Discharge Over current detection current 2 180±10A Short Protection YES Technical Specification size L160 * W63 * T20 mm NTC 10k Temperature switch /℃(the batteries temperature) Weak currentswitch / Active balance / Heater / Braking Resistors / Other Parameter Low temperature protOperating Temperature Range -40～+85℃ Storage Temperature Range -40~+125℃ Temperature Parameter LCD display screen / LED light board / Bluetooth mode / 4G / GPS / Optional Configuration - AYAA TECHNOLOGY CO., LTD
